UA-Hub-Door
Mechanical
Dimensions: 174.9 x 126 x 32.9 mm (6.9 x 5 x 1.3″)
Weight: 363 g (12.8 oz)
Enclosure material: Polycarbonate
Mounting material: Polycarbonate
Hardware
Networking interface: (5) 10/100/1000 Base-T
Power method: PoE++
UL 294 Power-limited Class 2 PSU
UL 60950/62368 LPS/PS2 PSU
Max. power consumption: Without PoE output: 30W
With PoE output: 50W
PoE input: 50V DC, 1A
PoE output: PoE passthrough, (4) PoE, 50V DC, total 20W
Button: (1) Factory-reset
Digital input: Request to exit/request to enter/remote release/door position sensor
Dry output relay: Lock: 30V DC, 1A
Aux: 30V DC, 1A
Powered output relay: Lock: 12V DC, 1A
Aux: 12V DC, 0.33A
12V DC, 0.33A
Operating environment: Indoor use only
Ambient operating temperature: 0 to 40° C (32 to 104° F)
Ambient operating humidity: 5 to 95% noncondensing
UL 294 level: Destructive attack: Level I
Line security: Level I
Endurance: Level I
Standby power: Level I
UL 294 statement: Compliance with IEEE 802.3 (at or af) specifications was not verified as part of UL 294.
The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
CAN/ULC-60839-11-1 Grade: Grade assignment: 1
Certifications: CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
Document number, and issue date and/or revision level: UA-Hub-Door002, V01
UA-G2
Mechanical
Dimensions: 93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4″)
Weight: 82 g (2.9 oz)
Enclosure material: Polycarbonate, glass
Mounting: In wall, gang box
Weatherproofing: IP55
Hardware
Networking interface: (1) 10/100 MbE RJ45 port
Connectivity: BLE 4.1
Power method: PoE
UL 294 Power-limited Class 2 PSU
UL 60950-1/62368-1 LPS/PS2 PSU
Supported voltage range: 48V DC
Max. power consumption: 5W
ESD/EMP protection: Air: ±15kV, contact: ±8kV
Sensors: Proximity sensor
Speaker: (1) 8 ohm, 0.7W
Button: (1) Factory-reset
NFC frequency: 13.56 MHz
NFC read range: < 30 mm
NFC standards: ISO 14443A, 14443B, 15693
NFC technology: NFC Tag 1,2,3,4,5
MIFARE Classic
MIFAREPlus
MIFARE Ultralight
MIFARE DESFire
UA-Card
Mechanical
Dimensions: 85.6 x 53.98 x 0.84 mm (3.37 x 2.13 x 0.03″)
Weight: 5 g (0.18 oz)
Format: ISO 7810 ID-1
NFC frequency: 13.56 MHz
NFC technology: ISO/IEC 14443 Type A
MIFARE DESFire
UniFi Access Proprietary Security Protocol
