Camera
Image Sensor: 1/2.7″ Progressive Scan CMOS
Max. Resolution: 1920 × 1080
Min. Illumination: Colour: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR Cut Filter
Angle Adjustment: Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Lens
Focal Length & FOV:: 4 mm: horizontal FOV 91.5°, vertical FOV 46.1°, diagonal FOV 109.8°
Lens Mount: M12
Focus: Fixed
Aperture: F1.6
Illuminator
Supplement Light Range: Up to 30 m
IR Wavelength: 850 nm
Video
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Video Compression
Main stream: H.265+/H.265//H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate: 32 Kbps to 8 Mbps
H.264 Type: Baseline Profile/Main Profile/High Profile
H.265 Type: Main Profile
Region of Interest (ROI): Support 1 fixed region for main stream
Image Settings: Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
Day/Night Switch: Day, Night, Auto, Schedule
Image Enhancement: BLC, 3D DNR
Wide Dynamic Range (WDR): 120 dB
