Mechanical
Dimensions: Without radome: 520 x 520 x 308 mm (20.5 x 20.5 x 12.1″)
With radome: 525 x 525 x 315 mm (20.7 x 20.7 x 12.4″
Weight: Without radome: 2.35 kg (5.2 lb)
With radome: 3.2 kg (7 lb)
Enclosure material: UV-stabilized plastic
Mounting: Pole mount kit (Included)
Wind loading: 264.6 N at 96 km/h (60 lbf at 60 mph)
Wind survivability: 96 km/h (60 mph)
Hardware
Networking interface: (1) GbE RJ45 port
Power method: Passive PoE 2-pair (4, 5+; 7, 8 return)
Power supply: 24V, 0.5A gigabit PoE adapter (Included)
Supported voltage range: 20-27V DC
Max. power consumption: 8.5W
ESD/EMP protection: Air/contact: ± 24 kV
LEDs: (1) Power, (1) LAN, (4) WLAN
Signal strength LEDs: Software-adjustable to correspond to custom RSSI levels
Salt fog test: IEC 68-2-11 (ASTM B117)
Equivalent: MIL-STD-810 G method 509.5
Vibration test: IEC 68-2-6
Temperature shock test: IEC 68-2-14
UV test: IEC 68-2-5 at 40° C (104° F)
Equivalent: ETS 300 019-1-4
Wind-driven rain test: ETS 300 019-1-4
Equivalent: MIL-STD-810 G method 506.5
Ambient operating temperature: -40 to 70° C (-40 to 158° F)
Ambient operating humidity: 5 to 95% noncondensing
Certifications: FCC, IC, CE, RoHS
System
Gain: 27 dBi
Max. VSWR: 1.5:1
Channel sizes
PtP Mode
PtMP Mode:
10/20/30/40/50/60/80 MHz
10/20/30/40 MHz
Polarization: Dual linear
