802.11k/802.11v seamless roaming switches clients automatically to the access point with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.
HARDWARE FEATURES
Interface: 2 × Gigabit Ethernet (RJ-45) Port (One port supports IEEE802.3af PoE and Passive PoE)
Physical Security Lock: Yes
Button: Reset
Power Supply: 802.3af/A PoE
48V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)
Power Consumption: 12.3 W
Dimensions ( W x D x H ): 205.5 × 181.5 × 37.1 mm
Antenna Type: Internal Omni
2.4GHz: 3* 3.5dBi
5GHz: 3*4dBi
Mounting: Ceiling /Wall Mounting (Kits included)
Hardware Watch Dog: Yes
WIRELESS FEATURES
Wireless Standards: IEEE 802.11ac/n/g/b/a
Frequency: 2.4GHz and 5GHz
Signal Rate: 5GHz:Up to 1300Mbps
2.4GHz:Up to 450Mbps
Wireless Functions: Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
MU-MIMO
Seamless Roaming
Band Steering
Load Balance
Airtime Fairness
Beamforming
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless Security: Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise,
WPA-PSK / WPA2-PSK
Transmission Power: CE：
≤20dBm(2.4GHz)
≤23dBm(5GHz)
FCC:
≤24dBm(2.4GHz)
≤24dBm(5GHz)
MANAGEMENT
Omada App: Yes
Centralized Management: Omada Software Controller
OC200
Cloud Access: Yes (Through Omada Software Controller or OC200)
EAP Controller Software: Yes
Email Alerts: Yes
LED ON/OFF Control: Yes
Management MAC Access Control: Yes
SNMP: Yes
System Logging Local/Remote Syslog: Local/Remote Syslog
Telnet: Yes
SSH: Yes
Web-based Management: HTTP/HTTPS
L3 Management: Yes
Multi-site Management: Yes
Management VLAN: Yes
