Mechanical
Dimensions: 649 x 426 x 303 mm (25.6 x 16.8 x 11.9″)
Weight: 10.5 kg (23.2 lb)
Mounting: Pole mount kit (Included)
Wind loading: 480 N @ 200 km/h (108 lbf @ 125 mph)
Wind survivability: 200 km/h (125 mph)
Hardware
Networking interface: (1) GbE RJ45 port
(1) 10/100 MbE RJ45 port
Auxiliary port: (1) RJ-12, alignment tone port
Power method: Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 😎
Power supply: 50V, 1.2A gigabit PoE adapter (Included)
Supported voltage range: 42–58V DC
Max. power consumption: 50W
Operating frequency: 24.05 – 24.25 GHz
Ambient operating temperature: -40 to 55° C (-40 to 131° F)
Certifications: CE, FCC, IC
System
Max. throughput: 1.5+ Gbps
Ma. range: 13+ km
Packets per second: 1+ million
Encryption: 128-bit AES
Uplink/Downlink ratio: Programmable in Half Duplex mode
RF
GPS: GPS clock synchronization
EIRP: ~33 dBm (FCC/IC), ~20 dBm (CE), ~40 dBm (Other Regions)
Frequency accuracy: ±2.5 ppm without GPS synchronization, ±0.2 ppm with GPS synchronization
Channel bandwidth: 100 MHz
Operating frequency: 24.05 – 24.25 GHz
Operating channels: 24.1 GHz, 24.2 GHz
Modulation: 64QAM MIMO, 16QAM MIMO, QPSK MIMO, QPSK SISO, ¼x QPSK SISO
Gain
TX: 33 dBi
RX: 38 dBi
Beamwidth: < 3.5° Front-to-back ratio: 70 dB Polarization: Dual-slant Cross-polarity Iiolation: > 28 dB
