Specifications
Product code: GPEN21
Switch chip model: 88E6341
Input voltage: 12 – 57 V, Passive or 802.3af/at
Tested ambient temperature: -20°C to 70°C
Powering
Number of DC inputs: 2 (DC jack, PoE-IN)
DC jack input Voltage: 12-57 V
Max power consumption: 30 W
Max power consumption without attachments: 3 W
Cooling type: Passive
PoE in: 802.3af/at
PoE in input Voltage: 12-57 V
PoE-out
PoE-out ports: Ether2
PoE out Passive: PoE up to 57V
Max out per port output (input 18-30 V): 850 mA
Max out per port output (input 30-57 V): 625 mA
Max total out (A): 850 mA
Ethernet
10/100/1000 Ethernet ports: 2
Number of 1G Ethernet ports with PoE-out: 1
Fiber
SFP ports: 1
Other
Output Voltage: Yes, Passive PoE up to 57 V
Mode button: Yes
