**Technical Specifications****Output**Max Configurable Power (Watts): 1.2kWatts / 2.2kVA Output Frequency (sync to mains): 50/60 Hz +/- 1 Hz Sync to mains Topology: Line interactive Waveform type: Stepped approximation to a sinewave Transfer Time: 6 ms typical : 10 ms maximum **Input**Input frequency: 50/60 Hz +/- 5 Hz Auto-sensing Input voltage range for main operations: 140 – 300V Number of Power Cords: 1 Input Power Factor at Full Load: 0.54 **Batteries & Runtime**Battery type: Lead-acid battery Typical recharge time: 8hour(s) Expected Battery Life (years): 1 – 2 Battery Volt-Amp-Hour Capacity: 216 **Communications & Management**Interface Port(s): USB Control panel: LED Status display with on line : on battery Audible Alarm: Alarm when on battery : distinctive low battery alarm **Surge Protection and Filtering**Surge energy rating: 273Joules Data Line Protection: RJ45 10/100/1000 Base-T Ethernet protection
