Mechanical
Dimensions: 135 x 185 x 32 mm (5.3 x 7.3 x 1.3″)
Weight: 1.2 kg (2.7 lb)
Enclosure material: Polycarbonate

Hardware
Management interface: Ethernet In-Band
Networking interface: (1) GbE, PoE+ RJ45 port
(4) 10 GbE RJ45 ports
Total non-blocking throughput: 41 Gbps
Switching capacity: 82 Gbps
Forwarding rate: 61.012 Mpps
Power method: (1) PoE+, 50—57V DC, 25W
(1) USB Type-C, 5V DC, 5A
Power supply: PoE+ (Pins 1, 2+/3, 6- or 4, 5+/7, 😎
AC/DC power adapter, 5V DC, 5A, 1.5 m cord (Included)
Supported voltage range: 90—264V AC (Adapter)
Max. power consumption: 25W
ESD/EMP protection: Air: ± 16kV, contact: ± 12kV
Button: Factory reset
Ambient operating temperature: -5 to 45° C (23 to 113° F)
Ambient operating humidity: 10 to 90% noncondensing
Certifications: CE, FCC, IC

Switching Features
Layer 2 features:

IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
