Hardware
Dimensions: 294 x 31 x 80 mm (11.6 x 1.3 x 3.2″)
Weight: 400 g (14.1 oz)
Enclosure material: Outdoor UV-stabilized plastic
Mounting: Pole-mount (Kit included)
Hardware
Networking interface: (2) 10/100 MbE RJ45 ports
Power method: Passive PoE 2-pair (4, 5+; 7, 8 return)
Power supply: 24V, 0.5A PoE adapter (Included)
Supported voltage range: 22–27V DC
Max. power consumption: 8W
Ambient operating temperature: -30 to 75° C (-22 to 167° F)
Operating Humidity: 5 to 95% noncondensing
Shock & vibration: ETSI300-019-1.4
Certifications: FCC, ICC, CE, RoHS
System
Frequency: 5 GHz
Operating frequency
Worldwide
USA
USA DFS:
5170-5875 MHz
5725-5850 MHz
5250-5850 Mhz
Gain: 14.6-16.1 dBi
Cross-pol isolation: 22 dB Min.
Max. VSWR: 1.6:1
Beamwidth: 43° (H-pol) / 41° (V-pol) / 15° (Elevation)
Polarization: Dual Linear
