Mechanical
Dimensions: 442.4 x 267.5 x 43.7 mm (17.4 x 10.5 x 1.7″)
Weight: 4 kg (8.8 lb)
Enclosure materials: SGCC steel, polycarbonate/acrylonitrile butadiene styrene
Hardware
Networking interface
24x GbE RJ45 LAN ports
4x 1/10G SFP+ ports
Management interface:
Ethernet In-band
Bluetooth
Total non-blocking throughput: 64 Gbps
Switching capacity: 128 Gbps
Forwarding rate: 95.23 Mpps
Power method
1x Universal AC input, 100-240V AC, 4.4A Max., 50/60 Hz
1x Power TransPort DC input 27V DC, 9.3A
Power supply: AC/DC, Internal, 250W
Supported voltage range: 100—240V AC
Max. power consumption: 30W (Excluding PoE output)
ESD/EMP protection: Air: ± 15 kV, contact: ± 8 kV
LCM display: 1x 1.3″ touchscreen
Ambient operating temperature: -10 to 50° C (14 to 122° F)
Ambient operating humidity: 5 to 95% noncondensing
Certifications: CE, FCC, IC
PoE
PoE interface: 16x 27V passive PoE: 2-pair (Pins 4, 5+/7, 😎 or 4-pair (Pins 1, 2, 4, 5+/3, 6, 7, 8-); Ports 1 to 16
Total available PoE: 220W
Max. passive PoE wattage per port: 30W/27V DC
Passive PoE voltage range: 27V DC
