Camera
Image Sensor: 1/1.8” Progressive Scan CMOS
Shutter Speed: 1/3 to 1/10000 s
Slow Shutter: Yes
Aperture: 4 mm: F1.0
Lens: Fixed focal lens (4 mm / 6 mm)
Lens Mount: M12
Minimum Illumination: Colour: 0.0005 Lux; 0 Lux with white light
Day/Night Switch: Day/Night/Auto/Schedule-Switch
White LED: Quantity: 4
Digital Noise Reduction: 3D DNR
WDR: 120dB
Weatherproof Rating: IP67
Illumination Distance: 30 m
Viewing Angle: 4mm: Horizontal FOV: 95.2°, Vertical FOV: 50.6°, Diagonal FOV: 114.7°
LENS
Type: Fixed Focal Lens
Focal Length: 4 mm
Aperture: F1.0
FOV: 4mm: Horizontal FOV: 95.2°, Vertical FOV: 50.6°, Diagonal FOV: 114.7°
Lens Mount: M16*P 0.5
DORI Distance:
4 mm:
Detect: 70 m (231 ft)
Observe: 29 m (96 ft)
Recognize: 14 m (46 ft)
Identify: 7 m (23 ft)
Angle Adjustment (Manual)
Range:
Pan: -90° to 90°
Tilt: -90° to 90°
Illuminator
White LED:
Quantity: 4
Range: 30m
Illuminator On/Off Control: Auto/Scheduled/Always on/Always off
Video
Max. Resolution: 2688 x 1520
Main Stream:
Frame Rate：
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
2688×1520, 2560×1440, 2304×1296, 2048×1280, 1920×1080, 1280×720
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Sub-Stream:
Frame Rate：
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
640×480, 352×288, 320×240
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Bit Rate Control: CBR, VBR
Video Compression:
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264
H.264 Type: Main Profile/High Profile
H.264+: Main Stream Supported
H.265 Type: Main Profile
H.265+: Main Stream Supported
Video Bit Rate:
Main Stream: 256 Kbps to 6 Mbps
Sub-Stream: 64 Kbps to 512 Kbps
Audio
Audio Communication: Two-Way Audio
Audio Input: Yes
Audio Output: Yes
Audio Compression: Yes
Audio Sampling Rate: 8KHz
Environment Noise Filtering: Yes
Audio Bit Rate: 64 Kbps(G.711 alaw)
