- 8× 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
- Green Ethernet technology saves power consumption
- IEEE 802.3x flow control provides reliable data transfer
- Steel housing, desktop or wall-mounting design
- Support 802.1p/DSCP QoS and IGMP Snooping function
- Plug and play, no configuration needed
- Loop Prevention: Monitor and address loop-related issues within your network structure to prevent disruptions caused by looping
HARDWARE FEATURES
Standards and Protocols: IEEE 802.3i / 802.3u / 802.3ab/ 802.3x /802.1p
Interface: 8 10/100/1000Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX
Fan Quantity: Fanless
External Power Supply: External Power Adapter (Output: 9VDC / 0.6A)
Buffer Size: 1.5Mb
LED Indicator: System Power
Link/Act indicators per port built into each RJ-45 port
Dimensions ( W x D x H ): 158 x 101 x 25 mm
Max Power Consumption: 3.31W(220V/50Hz)
Max Heat Dissipation: 11.29BTU/h
PERFORMANCE
Packet Forwarding Rate: 11.9Mpps
MAC Address Table: 4K
Packet Buffer Memory: 1.5Mb
Jumbo Frame: 16KB
SOFTWARE FEATURES
Advanced Features:
– Green Technology
– 802.3X Flow Control
– 802.1p/DSCP QoS
– IGMP Snooping
– Looping Prevention
Transfer Method: Store and Forward
