- 8 10/100/1000Mbps RJ45 ports
- With four PoE ports, transfers data and power on one single cable
- Working with IEEE 802.3af compliant PDs, expands home and office network
- Requires no configuration and installation
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Supports PoE power up to 15.4W for each PoE port
- Supports PoE power up to 55W for all PoE ports
HARDWARE FEATURES
Interface:
– 8 10/100/1000Mbps RJ45 Ports
– AUTO Negotiation/AUTO MDI/MDIX
Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity: Fanless
Physical Security Lock: No
External Power Supply: External Power Adapter(Output: 48VDC / 1.25A)
PoE Ports (RJ45):
– Standard: 802.3 af compliant
– PoE Ports: Port1- Port4
– Power Supply: 55W
Backbound Bandwidth: 16Gbps
Mac Address Table: 4K
Dimensions ( W x D x H ): 171*98*27 mm
Max Power Consumption:
– 5.49W(220/50Hz. no PD connected)
– 65.24W(220/50Hz. with 55W PD connected)
Max Heat Dissipation:
– 18.73BTU/h(no PD connected)
– 222.60BTU/h(with 55W PD connected)
