- – 8 10/100Mbps auto-negotiation RJ45 ports, supports auto MDI/MDIX
- – Green Ethernet technology saves power consumption
- – IEEE 802.3x flow control provides reliable data transfer
- – Plastic case, desktop design
- – Plug and play, no configuration required
HARDWARE FEATURES
Standards and Protocols: IEEE 802.3, IEEE 802.3u, IEEE 802.3x CSMA/CD
Interface: 8 10/100Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX
Fan Quantity: Fanless
Power Supply: External Power Adapter(Output: 5.0VDC / 0.6A)
External Power Supply: 100-240VAC, 50/60Hz
Buffer Size: 768Kb
Data Rates: 10/100Mbps at Half Duplex ; 20/200Mbps at Full Duplex
LED Indicator: Power, 1, 2, 3, 4, 5, 6, 7, 8
Dimensions ( W x D x H ): 5.3*3.1*0.9 in. (134.5*79*22.5mm)
Max Power Consumption: 2.05W(220V/50Hz)
Max Heat Dissipation: 6.99BTU/h
SOFTWARE FEATURES
Transfer Method: Store and Forward
Advanced Functions: Green Technology 802.3X Flow Control, Back Pressure
