The TL-MR150 uses 4G LTE technology to achieve speeds of up to 150Mbps download and 50Mbps upload. It also shares a Wi-Fi network with maximum speed of 300Mbps on 2.4GHz for gaming, streaming, and more.
Cutting-edge 4G network – share internet access with up to 32 Wi-Fi devices and enjoy download speeds of up to 150 Mbps
Plug a SIM card and play – no configurations needed, compatibility of SIM cards in 100+ countries are assured by years of field tests
Two detachable advanced LTE antennas – enjoy stable and efficient connections to every device thanks to the two external antennas
Wi-Fi router mode – plug an Ethernet cable into the LAN/WAN port for flexible access as a backup option if you can’t get a 4G connection
HARDWARE FEATURES
Interface: 3 10/100Mbps LAN Ports, 1 10/100Mbps LAN/WAN Port, 1 Micro SIM Card Slot
Button: WPS/RESET Button, WiFi ON/OFF Button, POWER ON/OFF Button
External Power Supply: 9V/0.85A
Dimensions ( W x D x H ) 202 × 141 × 33.6 mm
Antenna Type: 2 × Detachable External 4G LTE Antennas
WIRELESS FEATURES
Wireless Standards: IEEE 802.11b, 802.11g, 802.11n
Frequency: 2.4 GHz
Signal Rate: 300 Mbps at 2.4 GHz
Reception Sensitivity: 11g 54M: -74dBm
11n HT20: -71dBm
11n HT40: -67dBm
Transmit Power: CE: < 20 dBm(2.4 GHz) Wireless Functions: Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics WAN Failover: Yes Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions Network Type: 4G: FDD-LTE Cat4 (800/900/1800/2100/2600MHz), TDD-LTE (1900/2300/2500/2600MHz) 3G: DC-HSPA+/HSPA+/HSPA/UMTS (900/2100MHz)
SOFTWARE FEATURES
Operating Modes: 3G/4G Router, Wireless Router
Management: Access Control, Local Management, Remote Management
WAN Connection Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
DHCP: Server, Client, DHCP Client List, Address Reservation
Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS: DynDns, NO-IP
VPN: PPTP VPN, IPSec VPN , OpenVPN
Access Control: Parental Controls, Local Management Control, Host List, Access
Control
Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding
Protocols: IPv4, IPv6
Guest Network: 2.4GHz guest network
