Wireless
Standards
Wi-Fi 7
IEEE 802.11be/ax 6 GHz
IEEE 802.11be/ax/ac/n/a 5 GHz
IEEE 802.11be/ax/n/b/g 2.4 GHz
WiFi Speeds
BE11000
6 GHz: 5764 Mbps (802.11be)
5 GHz: 4324 Mbps (802.11be)
2.4 GHz: 688 Mbps (802.11be)
WiFi Range
Broader Whole Home Coverage
TP-Link Mesh Technology
AI-Driven Mesh
Intelligently learns the network environment to provide ideal Wi-Fi unique to your home
4× High-Performance Antennas (Internal)
Multiple antennas form a signal-boosting array to cover more directions and large areas
Tri-Band
A newly-opened 6 GHz band brings more bandwidth and faster speeds
WiFi Capacity
Very High
Tri-Band
Distribute devices to different bands for optimal performance
2×2 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple WiFi 7 clients
6 Streams
More than enough bandwidth for connected devices
Working Modes
Router Mode
Access Point Mode
Advanced Functions
Multi-Link Operation (MLO)
320 MHz Channel
4K-QAM
Multi-RUs
Works with Alexa and Google Assistant
Security
Network Security
SPI Firewall
Access Control
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner
Guest Network
1× 6 GHz Guest Network
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
Effective Time
Bandwidth Control
VPN Server
OpenVPN Server
PPTP VPN Server
L2TP/IPSec VPN Server
VPN Client
OpenVPN Client
PPTP VPN Client
L2TP/IPSec VPN Client
WiFi Encryption
WPA-Personal
WPA2-Personal
WPA3-Personal
Hardware
Ethernet Ports
4× 2.5 Gbps
*Per Deco Unit
Supports WAN/LAN auto-sensing
USB Support
1× USB 3.0 Port
FTP Server
Media Server
Samba Server
