- TP-Link’s First 4G+ Router – supports 4G+ Cat6 to boost the data speeds of up to 300 Mbps*
- Plug a SIM card and play – no configurations needed, compatibility of SIM cards in 100+ countries are assured by years of field tests
- MU-MIMO supported – simultaneous data streams increase WiFi throughput and network efficiency.
- Supports TP-Link OneMeshTM – co-works with TP-Link OneMesh products to create a flexible and cost-efficient Mesh network
- Better Signal for Connections Everywhere – enjoy stable and efficient connections to every device thanks to the two external LTE antennas
- Full Gigabit Ports – provides reliable wired connections for bandwidth-intensive devices such as game consoles and STB
- Wi-Fi router mode – plug an Ethernet cable into the LAN/WAN port for flexible access as a backup option if you can’t get a 4G connection
- Easy setup and management all by Tether app
HARDWARE FEATURES
Interface: 1 × 10/100/1000 Mbps LAN/WAN Port
3 × 10/100/1000 Mbps LAN Ports
1 × Micro SIM Card Slot
Button: WPS Button, Reset Button, WiFi On/Off Button, Power On/Off Button
External Power Supply: Power Adapter: Input Power 100-240v~50/60 Hz 0.6A
Output parameter 12VDC 1.5A
Dimensions ( W x D x H ): 9.0×6.3×1.5 in ( 229×160×37 mm)
Antenna: 2 × Detachable 4G LTE Antennas
WIRELESS FEATURES
Wireless Standards: IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency: 2.4 GHz and 5 GHz
Signal Rate: 300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz
Reception Sensitivity: 5 GHz: 11a 54M: -74 dBm
11ac HT20: -66 dBm
11ac HT40: -63 dBm
11ac HT80 : -59 dBm
11n HT20: -73 dBm
11n HT40: -70 dBm
2.4 GHz: 11g 54M: -74 dBm
11n HT20: -72 dBm
11n HT40: -69 dBm
Transmit Power: < 20 dBm (2.4 GHz), < 23 dBm (5 GHz) Wireless Functions: Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics WAN Failover: Yes Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions Network Type: 4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz) TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz) 3G: DC-HSPA+/HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz) SOFTWARE FEATURES
Quality of Service: Bandwidth Control
Security: DoS, IPv4 SPI Firewall, IPv6 Firewal, IP and MAC Address Binding, Access Control
WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
Management: TP-Link Cloud, Local Management, Remote Management
DHCP: Server, DHCP Client List, Address Reservation
Port Forwarding: ALG, Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS: TP-Link, DynDns, NO-IP
VPN: PPTP VPN, IPSec VPN , OpenVPN
Access Control: Parental Control, Local Management Control
Firewall Security: DoS, SPI Firewall, IP Address Filter/Domain Filter,
IP and MAC Address Binding
Protocols: IPv4, IPv6
Guest Network: 2.4 GHz Guest Network x 1, 5 GHz Guest Network x 1
