• Thermal Transfer print method
• Single LED status indicator
• Single button for feed/pause
• USB connectivity
• OpenACCESS™ for easy media loading
• Dual-wall frame construction
• ENERGY STAR qualified
• ZebraDesigner Essentials – easy label design tool free at
www.zebra.com/zebradesigner
Dimension
Thermal Transfer:
10.5 in. L x 7.75 in. W x 7.5 in. H
267 mm L x 197 mm W x 191 mm H
Printer Specifications
Resolution: 203 dpi/8 dots per mm
Memory: 128 MB Flash; 128 MB SDRAM
Maximum Print Width: 4.09 in./104 mm
Print Speed: 4 in./102 mm per second
Media and Ribbon Characteristics
Maximum Label Length: 39.0 in./991 mm
Media Width: 1.00 in./25.4 mm to 4.4 in./112 mm
Media Roll Size: 5.00 in./127 mm outer diameter Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1 mm)
Thickness: 0.003 in. (0.08 mm) min.; 0.0075 in. (.1905 mm) max. (tear-off mode only)
Media Types: Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands
Ribbon Outside Diameter: 1.34 in./34 mm (74 m)
Maximum Ribbon Length: 244 ft. (74 m)
Operating Temp.: 40° to 105° F/4.4° to 41° C
Storage Temp.: -40° to 140° F/-40° to 60° C
Operating Humidity: 10% to 90% non-condensing
Storage Humidity: 5% to 95% non-condensing
Fonts/Graphics/Symbologies
Bar Code Ratios: 2:1 and 3:1
1D Bar Codes: Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code
2D Bar Codes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec
