Printing Method: Impact dot matrix
Number of Pins: 9 pins
Number of columns: 80 columns
Pins: 18 Needles (2 x 9)
Printing Speed: HighSpeed-Draft: 10 cpi: 612 chars/s, Draft: 10 cpi: 463 chars/s, NLQ: 10 cpi: 115 chars/s
Barcodes: Coda bar (NW-7), Code 128, Code 39, Industrial 2 of 5, Matrix 2 of 5, POSTNET, UPC-A, UPC-E
Carbon Copies: 6 plus one original
Character Sets: 42
Character Tables: PCAPTEC, PC437, PC720, PC850, PC858, ISO-8859-15, Roman 8, Italic
Printing Resolution: 240 x 144 DPI
Interfaces: USB, Bidirectional parallel
Document Feed: Single sheet front and rear, Continuous paper front and rear, Paper output rear
Paper Formats: Sheet Paper (single- and multi-layer), Continuous Paper (single- and multi-layer), Envelopes, Cardboard
Paper Thickness Continuous Paper: 0.46 mm
Paper Thickness Label Base Sheet: 0.46 mm
Paper Thickness Multi Part: 0.12 mm – 0.46 mm
Paper Thickness Single Sheet: 0.06 mm – 0.14 mm
Power consumption: 54 Watt, 0.5 Watt (economy), 8 Watt (standby)
Supply Voltage: AC 198 V – 264 V
Product dimensions: 414 x 375 x 177 mm (Width x Depth x Height)
Product weight: 7.2 kg
Supported Temperature: Operation 5° C – 35° C, Storage -30° C – 60° C
Supported Humidity: Operation 10% – 80%, Storage 30% – 60%
Mean Time Between Failures: 25,000 hours
Print Head Life: 400 Million Strokes/Wire
Fonts: Bitmap font EPSON Draft (10 CPI, 12 CPI, 15 CPI), Bitmap font EPSON OCR-B (10 CPI), Bitmap font EPSON Roman (10 CPI, 12 CPI, 15 CPI, Proportional), Bitmap font EPSON Sans Serif (10 CPI, 12 CPI, 15 CPI, Proportional): Noise Level
Operation: 55 dB (A)
Ribbon Yield: 7500000 characters Black Draft
