Specifications
Architecture: ARM 64bit
CPU: 88F7040
CPU core count: 4
CPU nominal frequency: 350-1400 (auto) MHz
Switch chip model: 88E6393
RouterOS license: 5
Operating System: RouterOS v7
Size of RAM: 1 GB
Storage size: 1 GB
Storage type: NAND
MTBF: Approximately 200’000 hours at 25C
Tested ambient temperature: -40°C to 60°C
IPsec hardware acceleration: Yes
Powering
Number of DC inputs: 3 (PoE-IN, DC jack, 2-pin terminal)
DC jack input Voltage: 24-57 V
2-pin terminal input Voltage: 24-57 V
Max power consumption: 25 W
Max power consumption without attachments: 14 W
Cooling type: Passive
PoE in: 802.3af/at
PoE in input Voltage: 24-57 V
Ethernet
10/100/1000 Ethernet ports: 7
Number of 2.5G Ethernet ports: 1
Fiber
SFP+ ports: 1
Peripherals
Number of USB ports: 1
USB Power Reset: Yes
USB slot type: USB 3.0 type A
Max USB current (A): 1.5
