excerpt: Huawei eKitEngine AP160 is a Wi-Fi 6 (802.11ax) wall plate access point (AP). It can simultaneously provide services on 2.4 GHz (2×2 MIMO) and 5 GHz (2×2 MIMO) frequency bands, achieving a device rate of up to 1.775 Gbps
wpid: 677665
product_brand:
  - Huawei
product_type:
  - simple
product_cat:
  - Access Points
  - Networking
featured_image: "https://tech.co.za/wp-content/uploads/2026/06/ap160a.png"
featured_image_alt: huawei wireless ap160 indoor wi fi smart antenna
---

| Maximum power consumption \[W\] | 9.1 |
| --- | --- |
| Power supply mode | PoE |
| Input voltage range \[V\] | PoE: 802.3af |
| Service port surge protection \[kV\] | PoE port: Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion C |
| Maximum number of physical ports on the entire device | GE (RJ45) x 2, 10M/100M/1000M auto-sensing |
| Long-term operating temperature \[°C(°F)\] | –10°C to +50°C (14°F to 122°F) (If the altitude is in the range of 1800 m to 5000 m, the temperature decreases by 1°C or 1.8°F every time the altitude increases by 300 m.) |
| Storage temperature \[°C(°F)\] | –40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity \[RH\] | 5% RH to 95% RH |
| Long-term operating altitude \[m(ft.)\] | –60 m to +5000 m (–196.85 ft to +16404.20 ft) |
| Atmospheric pressure \[kPa\] | 53 kPa – 106 kPa ETSI 300 019-2-3 |
| Ground | floating ground |
| Radio number | 2 |
| Operating frequency band | • 2.4GHz • 5GHz |
| Radio interface | Built-in smart antennas |
| Antenna gain | 2.4G: 3 dBi/chain (peak) 3 dBi (combined gain) 5G: 2 dBi/chain (peak value) 1 dBi (combined gain) |
| Maximum transmit power | 2.4G: 17 dBm/chain 20 dBm (combined power) 5G: 17 dBm/chain 20 dBm (combined power) |
| Single-frequency transmit power \[dBm\] | 2.4G: 0 dBm~17 dBm /chain 5G: 0 dBm~17 dBm /chain |
