Thermal Module
- Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
- Resolution 160 × 120
- Pixel Pitch 17 μm
- Spectral Range 8 μm to 14 μm
- NETD < 40 mK (@ 25 °C, F# = 1.1)
- Focal Length 9.7 mm
- IFOV 1.75 mrad
- Field of View 15.96° × 12.00° (H × V)
- Min. Focusing Distance 1.2 m
- Aperture F1.1
- Digital Zoom × 2, × 4
Optical Module
- Image Sensor 1/2.7″ Progressive Scan CMOS
- Resolution 2688 × 1520
- Min. Illumination 0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
- Shutter Speed 1s to 1/100,000s
- Focal Length 8 mm
- Field of View 39.42° × 22.14° (H × V)
- Aperture (Range) F1.6
- WDR 120 dB
Image Effect
- Target Coloration Yes. Supported in white hot and black hot mode.
Illuminator
- IR Distance Up to 40 m
- IR Intensity and Angle Automatically adjusted
Audible and Visual Alarm
- White Light Range Up to 40 m
- Visual Alarm Yes. White light alarm with adjustable flashing frequencies
- Audio alarm Yes, for two types of audible alarm (VCA and Temperature Exception)2 preset voice alerts (one for each)6 importable user-defined voice alerts (6 options shared in the two types)
Smart Function
- VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
- Temperature Measurement 3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
- Temperature Range – 20 °C to 150 °C (- 4 °F to 302 °F)
- Temperature Accuracy ± 8 °C (± 14.4 °F)
- General Function Fire detection, smoking detection, sun-reflection filter,
Video and Audio
- Main Stream Thermal:25 fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240)Optical:50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-stream Thermal:25 fps (704 × 576, 352 × 288, 320 × 240)Optical:50 Hz: 25 fps (704 × 576, 352 × 288)60 Hz: 30 fps (704 × 480, 352 × 240)
- Video Compression Main Stream: H.265/H.264Sub-Stream: H.265/H.264/MJPEG
- Audio Compression G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Network
- Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PP PoE, TLS
- Network Storage MicroSD/SDHC/SDXC card (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
- API ISAPI, HIKVISION SDK,ISUP, and third-party management platform, Open Network Video Interface, ONVIF (Profile S, Profile G, Profile T)
- Simultaneous Live View Up to 20 channels
- User/Host level Up to 32 users, 3 levels: Administrator, Operator, User
- Security User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
- Client iVMS-4200, Hik-Connect
- Web Browser Live view (plug-in allowed) : Internet Explorer 11Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +Local service : Chrome 57.0 +, Firefox 52.0 +
Interface
- Alarm Input 2, alarm input (0-5 VDC)
- Alarm Output 2, alarm output (alarm response actions configurable)
- Alarm Action recording/Relay output/Smart capture/FTP upload/Email linkage
- Audio Input 1, 3.5 mm Mic in/Line in interface, Line input: 2-2.4 V [p-p], output impedance: 1 KΩ ± 10%
- Audio Output Linear level, impedance: 600 Ω
- Communication Interface 1, RJ45 10 M/100 M Self-adaptive Ethernet interface.1, RS-485 interface (half duplex)
- Analog Output 1.0V [p-p]/75Ω, PAL/NTSC/BNC
General
- Web Client Language 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
- Power Supply 12 VDC ± 25%, φ 5.5 mm coaxial power plug, PoE (802.3af, class 3)
- Power Consumption 12 VDC ± 25%: 0.5 A, Max 6 W PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, Max 6.5 W
- Working Temperature/Humidity Temperature: -40°C to 65°C (-40°F to 149°F)Humidity: 95% or less
- Protection Level IP67 Standard, TVS 6000V lightning protection, surge protection, voltage transient protectionIK10-rated housing
- Dimensions 358.3 mm × 113.5 mm × 115.2 mm (14.10″ × 4.47″ × 4.35″)
- Weight Approx. 1.76 kg (3.88 lb)
Detection Range Table/Smart Function Range
- VCA Range for Humans 50 m
- VCA Range for Vehicles 150 m
