Camera
- Image Sensor [Bullet channel]: 1/3″ Progressive Scan CMOS; [PTZ channel]: 1/2.8″ progressive scan CMOS
- Max. Resolution [Bullet channel] 2560 × 1440, [PTZ channel] 2560 × 1440
- Min. Illumination [Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light;[PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR
- Shutter Speed 1 s to 1/30,000 s
- Day & Night ICR
- Zoom [PTZ channel] 25 × optical, 16 × digital
- Slow Shutter yes
Lens
- Focal Length [Bullet channel]: 2.8 mm; [PTZ channel]: 4.8 to 120 mm, 25 × optical
- FOV [Bullet channel]: Horizontal field of view: 96.1°, Vertical field of view: 52.1°，Diagonal field of view: 113.3°;[PTZ channel]:Horizontal field of view: 55° to 2.4° (wide-tele),Vertical field of view: 33° to 1.4° (wide-tele),Diagonal field of view: 61.5° to 2.8° (wide-tele)
- Focus semi-auto||manual||auto
- Aperture [Bullet channel]: F1.0; [PTZ channel]: F1.6
- Zoom Speed [PTZ channel]: approx. 3.6 s
Illuminator
- Supplement Light Type [PTZ channel]: IR; [Bullet channel]: White Light
- Supplement Light Range [PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m
- Smart Supplement Light Yes
PTZ
- Movement Range (Pan) 360°
- Movement Range (Tilt) -15° to 90° (auto flip)
- Pan Speed pan speed: configurable from 0.1° to 80°/s; preset speed: 80°/s
- Tilt Speed tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s
- Proportional Pan yes
- Presets 300
- Preset Freezing yes
- Patrol Scan 8 patrols, up to 32 presets for each patrol
- Pattern Scan 4 pattern scans
- Park Action preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan
- 3D Positioning yes
- PTZ Status Display yes
- Scheduled Task preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output
- Power-off Memory yes
Video
- Main Stream [Bullet channel]:50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)[PTZ channel]:50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
- Sub-Stream [Bullet channel]:50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)[PTZ channel]:50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
- Third Stream [Bullet channel]:50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)[PTZ channel]:50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Video Compression H.265||H.264||MJPEG
- Video Bit Rate 32 kbps to 16384 kbps
- H.264 Type baseline profile||main profile||high profile
- H.265 Type main profile
- Scalable Video Coding (SVC) yes
- Region of Interest (ROI) 8 fixed regions for each stream
Audio
- Audio Compression G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC
- Audio Bit Rate 32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC)
- Audio Sampling Rate 8 kHz,16 kHz,32 kHz,48 kHz
- Environment Noise Filtering yes
Network
- Protocols IPv4/IPv6||HTTP||HTTPS||802.1x||Qos||FTP||SMTP||UPnP||SNMP||DNS||DDNS||NTP||RTSP||RTCP||RTP||TCP/IP||UDP||IGMP||ICMP||DHCP||PP PoE||Bonjour||WebSocket||Web Sockets
- Simultaneous Live View 20
- API Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
- User/Host 32
- Security Authenticated username and password||MAC address binding||HTTPS encryption||802.1X authenticated access||IP address filter
- Network Storage NAS (NFS, SMB/ CIFS)|| ANR
- Client iVMS-4200||Hik-Connect
- Web Browser IE 10+, Chrome 57+, Firefox 52+, Safari 12+
- Image Parameters Switch Yes
- Image Settings sharpness, saturation, brightness, contrast
- Day/Night Switch day, night, auto, scheduled-switch
- Wide Dynamic Range (WDR) 120 dB
- SNR ≥ 52 dB
- Defog Digital defog
- Image Stabilization EIS
- Image Enhancement BLC,HLC,3D DNR
- Privacy Mask [Bullet channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable
- Regional Focus Yes
- Regional Exposure Yes
Interface
- Ethernet Interface RJ45, self-adaptive 10M/100M Ethernet port
- On-board Storage Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB
- Audio 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1 audio output, line level, impedance: 600 Ω
- Alarm 1 alarm input, 1 alarm output
- Reset yes
Event
- Basic Event [PTZ channel] motion detection, video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot)
- Smart Event [PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection,[Bullet channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection
- Linkage [Bullet channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, and trigger recording, [PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan)
Deep Learning Function
- Face Capture [Bullet channel] no,[PTZ channel] yes
General
- Power 12VDC, PoE+
- Dimension Ø 166 mm × 375 mm (Ø 6.5″ × 14.7″)
- Weight Approx. 2.4 kg (13.2 lb.)
- Material ADC12
- Operating Condition -30℃ to 65℃ (-22°F to 149°F) ||humidity lower than 90%RH
- General Function mirror,password protection,watermark,IP address filter
- Demist Demist by heating the glass
- Power Consumption and Current Max. 24 W, including max. 2.6 W for heater and max. 11 W for supplement light
Approval
- Protection IP66 Standard, 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection
