General
Shell: Metal material
Net Weight: 2.59 kg (5.71 lb)
Gross Weight: 3.68 kg (8.11 lb)
Dimensions (W × H × D): 440.00 mm × 44.00 mm × 220.80 mm (17.32” × 1.73” × 8.69”)
Operating Temperature: 0 °C to 45 °C (0 °F to 113 °F)
Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
Operating Humidity: 5% to 95% (no condensation)
Relative Humidity: 5% to 95% (no condensation)
Power Supply: 100-240 VAC, 50/60 Hz, Max. 4 A
Installation Mode: Rack (equipped with mounting ears)
Max. Power Consumption: 250 W
Power Consumption in Idle: 20 W
Surge Protection: 6 kV
Network Parameters
Ports: 16 × 10/100 Mbps PoE port,2 × Gigabit combo
MAC Address Table: 16 K
Switching Capacity: Whole-Device Performance: 9.2 Gbps
Port Performance: 7.2 Gbps
Packet Forwarding Rate: Whole-Device Performance: 6.84 Mpps
Port Performance: 5.36 Mpps
Internal Cache: 4 Mbits
PoE Power Supply
PoE Standard: IEEE 802.3af,IEEE 802.3at
PoE Power Pin: 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
PoE Port: PoE: Ports 1 to 16
Max. Port Power: 30 W
PoE Power Budget: 230 W
