Thermal Module
Image Sensor: Vanadium Oxide Uncooled Focal Plane Arrays
Resolution: 256 × 192
Pixel Pitch: 12 μm
Spectral Range: 8 μm to 14 μm
NETD: < 40 mK (25°C, F1.0)
Focal Length: 6.9mm
IFOV: 1.74 mrad
Field of View: 24.9° × 18.7° (H × V)
Min. Focusing Distance: 1 m
Aperture: F1.0
Digital Zoom: ×2, ×4
Optical Module
Image Sensor: 1/2.7″ Progressive Scan CMOS
Resolution: 2688 × 1520
Min. Illumination: 0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
Shutter Speed: 1 s to 1/100,000 s
Focal Length: 6.4 mm
Field of View: 53.0° × 28.0° (H × V)
Aperture (Range): F1.6
WDR: 120 dB
Illuminator
IR Distance: Up to 30 m
IR Intensity and Angle: Automatically adjusted
Audible and Visual Alarm
White Light Range: Up to 30 m
Smart Function
VCA: 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
Temperature Measurement: 3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
Temperature Range: -20°C to 150°C (-4°F to 302°F)
Temperature Accuracy: ± 8°C (± 14.4°F)
General Function: Fire detection, smoking detection, sun-reflection filter
Video and Audio: Main Stream
Thermal:
25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream
Thermal:
25 fps (704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (704 × 576, 352 × 288)
60 Hz: 30 fps (704 × 480, 352 × 240)
Video Compression
Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG
Audio Compression: G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
