Features
Smart Function
- All channels support Motion Detection 2.0
- 2-ch video analysis for human and vehicle recognition to reduce false alarm
- 1-ch facial recognition for video stream, or 4-ch facial recognition for face picture
- Smart search for the selected area in the video, and smart playback to improve the playback efficiency
Professional and Reliability
- H.265+ compression effectively reduces the storage space by up to 75%
- Adopt stream over TLS encryption technology which provides more secure stream transmission service
HD Video Output
- Provide independent HDMI and VGA outputs
- HDMI video output at up to 4K resolution
Storage and Playback
- Up to 2 SATA interfaces for HDD connection (up to 10 TB capacity per HDD)
- 16-ch synchronous playback
Network & Ethernet Access
- 1 self-adaptive 10/100/1000 Mbps Ethernet interface
- Hik-Connect for easy network management
Technical Specification
- Up to 32-ch IP camera inputs (*Additional switch required for Camera’s)
- 1x RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- H.265+/H.265/H.264+/H.264 video formats
- Up to 2-ch@12 MP or 3-ch@8 MP or 6-ch@4 MP or 12-ch@1080p decoding capacity
- Up to 256 Mbps incoming bandwidth
- Up to 160 Mbps outgoing bandwidth
- Adopt Hikvision Acusense technology to minimize manual effort and security costs
- 1-ch HDMI Output
- 1-ch VGA Output
- HDMI/VGA independent output Mode
- 1-ch Audio Output, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
- 1-ch Two-Way Audio, RCA (Linear, 1 KΩ)
- 2x SATA interfaces
- Up to 10 TB capacity for each HDD
- 1x USB 2.0 Front panel, 1x USB 2.0 Rear panel
- 4x Alarm In, 1x Alarm Out
