Camera
- Image Sensor 2 MP CMOS
- Max. Resolution 1920 (H) × 1080 (V)
- Min. Illumination 0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR
- Shutter Time PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s
- Day & Night ICR
- Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360°
- Signal System PAL/NTSC
Lens
- Lens Type 2.8 mm fixed focal lens
- Focal Length & FOV 2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°
- Lens Mount M12
Illuminator
- Supplement Light Type White Light; IR
- Supplement Light Range IR : Up to 25 m, White Light : Up to 20 m
- Image Settings Brightness, Sharpness, Smart IR
- Frame Rate TVI: 1080P @ 30 fps, 1080P @ 25 fps, AHD: 1080P @ 30 fps, 1080P @ 25 fps, CVI: 1080P @ 30 fps, 1080P @ 25 fps, CVBS: PAL/NTSC
- Day/Night Mode Auto/Color/BW (Black and White)
- Wide Dynamic Range (WDR) Digital WDR
- Image Enhancement DWDR/BLC/HLC/Global
- White Balance Auto/Manual
- AGC Yes
Interface
- Video Output Switchable TVI/AHD/CVI/CVBS
- Built-In Microphone Yes
General
- Material Plastic
- Dimension 138.8 mm × 60.9 mm × 57.9 mm (5.47″ × 2.4 ” × 2.3″)
- Weight Approx. 155 g (0.34 lb.)
- Operating Condition -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- Communication HIKVISION-C
- Language English
- Power Supply 12 VDC ± 25%*You are recommended to use one power adapter to supply the power for one camera.
- Consumption Max. 3.3 W
Approval
- Protection IP67
