Camera
Image Sensor: 2 MP CMOS
Signal System: PAL/NTSC
Max. Resolution: 1920 (H) × 1080 (V)
Min. Illumination: 0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time: PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night: IR Cut Filter
Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
Lens
Lens Type; 2.8 mm, 3.6 mm Fixed Lens
Focal Length & FOV: 2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5°
Lens Mount: M12
Illuminator
Supplement Light Range: Up to 20 m
Frame Rate
TVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
CVBS: PAL/NTSC
Wide Dynamic Range (WDR): Digital WDR
Image Parameters Switch: STD/HIGH-SAT
Day/Night Mode: Auto/Colour/BW (Black and White)
White Balance: Auto
Image Enhancement: DWDR, BLC, Global
Noise Reduction: 2D DNR
Image Settings: Brightness, Mirror, Smart IR, Sharpness, AGC
