| Power | |
| Total power | 3000 W |
| AC input voltage | 220 – 240 V |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 130 W |
| Combined power (+12V) | 3000 W |
| Combined power (+5V) | 130 W |
| Combined power (-12V) | 0.8 W |
| Combined power (+5Vsb) | 3 W |
| Max output current (+3.3V) | 25 A |
| Max output current (+12V) | 250 A |
| Max output current (+5V) | 25 A |
| Max output current (-12V) | 9.6 A |
| Max output current (+5Vsb) | 15 A |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit,Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 61 cm |
| Number of SATA power connectors | 12 |
| SATA power cable length | 120,400 mm |
| Peripheral (Molex) | power |
| connectors (4-pin) | 3 |
| Peripheral (Molex) power cable length | 150,400 mm |
| PCI Express power connectors (6+2pin) | 4 |
| PCI Express power connectors (16-pin) | 4 |
| PCI Express power cable length | 75 cm |
| CPU power connector (4+4 pin) | ✔ |
| CPU power cable length | 100 cm |
| Cabling type | Fully-Modular |
