Management features
Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes
Web-based management: Yes
Traffic classification: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 48
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4
Network
Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support: Yes
IP routing: Yes
Full duplex: Yes
Spanning tree protocol: Yes
Auto-sensing: Yes
Auto MDI/MDI-X Auto MDI/MDI-X: Yes
Link aggregation: Yes
Rate limiting: Yes
Flow control support: Yes
VLAN support: Yes
Data transmission
Switching capacity: 176 Gbit/s
Throughput: 112 Mpps
MAC address table: 32768 entries
Latency (1 Gbps): 3.8 µs
Latency (10 Gbps): 1.6 µs
Packet buffer memory: 12.38 MB
Security
DHCP features: DHCP server
Access Control List (ACL): Yes
IGMP snooping: Yes
SSH/SSL support: Yes
Multicast features
Multicast support: Yes
Protocols
Routing protocols: IP
Design
Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Performance
Built-in processor: Yes
Processor model: ARM Cortex-A9
Processor frequency: 1016 MHz
Memory type: DDR3-SDRAM
Internal memory: 1024 MB
Power
Power supply included: Yes
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
Power consumption (max): 980 W
