OPERATIONAL
Light Source: 617 nm visible red LED
Optical System: Linear CCD array
Microprocessor: 32-bit
Depth of Field :4 mil: 0 – 60 mm
5 mil: 0 – 100 mm
7.5 mil: 0 – 180 mm
10 mil: 0 – 220 mm
13 mil: 0 – 300 mm
20 mil: 0 – 350 mm
(Note: DOF may vary depending on environment condition and barcode quality.)
Scan Rate: 330 scans per second
Scan Angle: 42°
Print Contrast: Min. 30% @ UPC/EAN 100%
Indicator: Blue LED
Beeper Operation: Programmable tone & beep time
System Interface: Keyboard, RS-232, HID USB, USB Virtual COM, wand, OPOS,JPOS
PHYSICAL
Dimension: 152.3 × 64.4 × 104.9 mm (device only)
Weight: 84 g (device only)
Cable: Standard 2M straight
POWER
Input Voltage: 5 VDC ±10%
Operating Current: 110 mA typical
REGULATORY
EMC: CE & FCC DOC compliant, VCCI, BSMI
Safety: IEC 62471 Exempt
