Mechanical
Dimensions: Ø206 x 46 mm (Ø8.1 x 1.8″)
Weight: 680 g (1.5 lb)
Enclosure material: Polycarbonate, metal
Mount material: Stainless steel (SUS304), galvanized steel (SGCC)
Hardware
Networking interface: 1x 1/2.5 GbE RJ45 port
Management interface: Ethernet
Power method: PoE+
Power supply: UniFi PoE switch
Supported voltage range: 44—57V DC
Max. power consumption: 21W
Max. TX power:
2.4 GHz: 22 dBm
5 GHz: 26 dBm
6 GHz: 23 dBm
MIMO
2.4 GHz: 2 x 2
5 GHz: 2 x 2
6 GHz: 2 x 2
Throughput rate
2.4 GHz: 688 Mbps
5 GHz: 2882 Mbps
6 GHz: 5765 Mbps
Antenna gain
2.4 GHz: 4 dBi
5 GHz: 6 dBi
6 GHz: 5.8 dBi
LEDs: White/blue
Button: Factory reset
Mounting: Wall/ceiling (Included)
Ambient operating temperature: -30 to 60° C (-22 to 140° F)
Ambient operating humidity: 5 to 95% noncondensing
