Mechanical
Dimensions: Ø109.2 x 64.5 mm (Ø4.3 x 2.5″)
Weight: Without mount: 370 g (13.1 oz)
With mount: 390 g (13.8 oz)
Enclosure material: Aluminum alloy, polycarbonate, hard-coated dome
Mount material: Polycarbonate, stainless steel
Weatherproofing: IPX4
Resistance: IK08
Optics
Sensor: 5MP CMOS
Lens: Fixed focal length
View angle: H: 102.4°, V: 54.9°, D: 120.6°
Night mode: Built-in IR LED illumination and IR cut filter
Video
Resolution: 4MP 2688 x 1512 (16:9)
Max. frame rate: 30 FPS
Image settings: Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
System
Processor: Dual-core Arm® Cortex®-A7 based chip
Networking interface: 10/100 MbE RJ45 port
Max. power consumption: 5W
Power method: PoE
Supported voltage range: 37–57V DC
LED: R/G/B/W
Button: Factory reset
Mounting: Wall, ceiling mount
Ambient operating temperature: -20 to 40º C (-4 to 104º F)
Ambient operating humidity: 0 to 90% noncondensing
Certifications: FCC, IC, CE
Audio
Microphone: Yes (Can be disabled)
Speaker: Yes
