Mechanical
Dimensions: 325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7″)
Weight: 2.1 kg (4.6 lb)
Enclosure material: SGCC steel
Hardware
Management interface: Ethernet In-Band
Networking interface
12x GbE RJ45 ports
4x 1/2.5 GbE RJ45 ports
2x 10G SFP+ ports
PoE interface
12x PoE/PoE+ (Pins 1, 2+; 3, 6-)
4x 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 😎
Total non-blocking throughput: 42 Gbps
Switching capacity: 84 Gbps
Forwarding rate: 62.496 Mpps
Power method: DC adapter
Power supply: 54V, 210W
Max. power consumption: 30W (Excluding PoE output)
Total available PoE: 180W
Max. PoE wattage per port by PSE
PoE: 15.4W
PoE+: 30W
PoE++: 60W
Voltage range PoE mode
PoE: 44—57V
PoE+/PoE++: 50—57V
LCM display: 1x 1.3″ touchscreen
Button: Factory reset
Ambient operating temperature: -5 to 40° C (23 to 104° F)
Ambient operating humidity: 10 to 90% noncondensing
Certifications: CE, FCC, IC
