Mechanical
Dimensions: 442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24″)
Weight 3.42 kg (7.54 lb)
Enclosure materials:
Front panel: aluminium CNC
Top cover/base: SGCC steel
Hardware
Processor: Quad-core ARM® Cortex ®-A57 at 1.7 GHz
Memory information: 2 GB DDR4
Management interface: Ethernet
Networking interface LAN:
1x 1 GbE RJ45 port
1x 10G SFP+ port
WAN:
1x 1 GbE RJ45 port
1x 10G SFP+ port
LCM display: 1x 1.3″ touchscreen
Bootup animation: bootup in progress
Firmware upgrade icon: rmware upgrading
Button Factory reset
Power supply: AC/DC, internal, 50W
Max. power consumption: 30W
ESD/EMP: protection Air: ± 15 kV, contact: ± 8 kV
Operating temperature: -10 to 40° C (14 to 104° F)
Operating humidity: 5 – 95% noncondensing
Certifications: CE, FCC, IC
