**Specification’s**
Dimensions: 442.4 x 285.6 x 43.7 mm (17.42 x 11.24 x 1.72″)
Weight (with Mount Brackets):
4.40 kg (9.7 lb)
4.495 kg (9.91 lb)
Networking Interfaces:
8x GPON OLT SFP
2x 1G/10G SFP+
Concurrent Clients: 1024 Registered ONUs/ONTs (128 per GPON Port)
Management Interfaces:
1x Ethernet for Out-of-Band Management
1x RJ45 Serial Console Port
GPON Speeds
2.488 Gbps Upstream (TX)
1.244 Gbps Downstream (RX)
Operating Wavelengths:
1490 nm TX
1310 nm RX
Normal Optical Power Range:
TX (Class B+): 1.5 dBm to 5 dBm
RX: -8 dBm to -28 dBm
Range:
Physical Reach: 20km
Logical Reach: 60 km
Max. Differential Fiber Distance: 20 km (B+) /40 km (C+)
Power Method:
100-240VAC, 100W AC/DC Power Module (Included)
38-54VDC, 100W DC/DC Power Module (Optional)
Power Supply: 1x 25V, 100W AC/DC PSU Module (Included)
Max. Power Consumption: 40W (Excluding SFP Modules)
Operating Mode: OLT 2/3 Ethernet Switch and GPON Core
Advanced QoS: Supports 8 Priority Queues per User Port and Traffic Classification
Processor Specs: MIPS 1004kc, 880 MHz Dual Core
Memory Information: 512 MB DDR3, 512 MB NAND
Operating Temperature: -10 to 45° C (14 to 113° F)
Operating Humidity: 10 to 90% Noncondensing
