Mechanical
Dimensions: 100 x 100 x 27 mm (3.9 x 3.9 x 1.1″)
Weight: 220 g (0.49 lb)
Enclosure material: UV-stabilized polycarbonate
Hardware
Networking interface: (1) SC/APC, ITU-G.987 XGPON WAN port, (1) 100/1,000/2,500 MbE RJ45 LAN ports
Management interface: Ethernet in-band, PON
PoE interface: (1) PoE in, 24V DC passive PoE
Memory: 256 MB DDR
Onboard flash storage: 32 MB NOR
Max. power consumption: 6W
Power method: USB-C 5V DC, 3A
24V DC passive PoE
Power supply: 5V DC, 3A power adapter, Passive PoE 2-pair (4, 5+; 7, 😎
Supported voltage range: 5V DC adapter, 10–30V DC passive PoE
Total non-blocking line rate: Downstream: 9.95 Gbit/s
Upstream: 2.44 Gbit/s
Normal TX range of optical module: 2 to 7dBm
Normal RX range of optical module: -9 to -27dBm
Button: (1) Factory reset
Ambient operating temperature: -15 to 45° C (5 to 113° F)
Ambient operating humidity: 10 to 95% non-condensing
Certifications: CE, FCC, IC
Fiber
Operating wavelength: TX: 1,270nm, RX: 1,577nm
Line code: Scrambled NRZ
Physical reach: 20 km
