Mechanical
Dimensions: 210.4 x 140.2 x 43.7 mm (8.3 x 5.5 x 1.7″)
Weight: 1.5 kg (3.2 lb)
Enclosure materials: SGCC steel, polycarbonate
Hardware
Processor: Quad-core ARM® Cortex®-A57 at 1.7 GHz
Memory: 4 GB DDR4
Onboard flash storage: 16 GB eMMC
Onboard storage: 128 GB SSD
Card slot
1x microSD
Networking interface
8x LAN: GbE RJ45 ports
1x LAN: 1/10G SFP+ port
1x WAN: GbE RJ45 port
1x WAN: 1/10G SFP+ port
Management interface:
Ethernet In-band
Bluetooth
Power method:
1x External AC/DC adapter
1x Power TransPort DC input 27V DC, 1.5A
Power supply
24V DC, 2.5A power adapter (included)
Supported voltage range: 24—28V DC
Max. power consumption: 30W
ESD/EMP protection: Air: ± 15kV, contact: ± 8kV
Ambient operating temperature: -10 to 50° C (14 to 122° F)
Ambient operating humidity: 5 to 95% noncondensing
