Mechanical
Dimensions: 284 x 156 x 76 mm (11.2 x 6.1 x 3″)
Weight: 1.3 kg (2.9 lb)
Enclosure material: Aluminum alloy, UV stabilized polycarbonate
Mount material: Stainless steel, UV stabilized polycarbonate
Pole mount diameter: 35 to 60 mm (1.4 to 2.4″) on pipe outer diameter
Wind loading: 87 N at 200 km/h (20 lbf at 125 mph)
Weatherproofing: IPX6
Hardware
Processor: Quad-core ARM® Cortex®-A53 at 1.4 GHz
Memory: DDR3L 512 MB
Networking interface: (1) 1/2.5 GbE RJ45 port
Max. power consumption: 24W
Power method: Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 😎
Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only
Power supply: 48V DC, 0.65A, 2.5 GbE PoE adapter (Included)
Supported voltage range: 44–54V DC
22–27V DC
GPS: Yes
Button: Factory reset
LEDs: Power, Ethernet, GPS, Link
Ambient operating temperature: -40 to 60° C (-40 to 140° F)
Ambient operating humidity: 5 to 95% noncondensing
Certifications: FCC, IC, CE
Software
Operating mode: PtMP access point
Ubiquiti specific features: Wave AI, discovery protocol
Services: UISP, ping watchdog, NTP client, SNMP
Tools: Antenna alignment, discovery utility, ping, trace route, speed test, cable test, site survey
*FW version 3.3.0 and later.
Network: Bridge mode
Application requirements: UISP web: Version 2.2.11 and later
UISP mobile iOS™: Version 2.25.1 and later
UISP mobile Android™: Version 2.27.5 and later
RF
Operating frequency*: 57–71 GHz
*Depends on regulatory region.
Channel bandwidth: 2160, 1080, 540* MHz
FW version 3.3.0 and later. Operating channels: 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz
*Depends on regulatory region.
Modulation: 16QAM, QPSK
Antenna gain: 20 dBi
Polarization: Vertically linear
Beamwidth: Azimuth: 3 dB 90°
Elevation: 3 dB 7°
Electrical downtilt: 0°
Back-Up RF
WiFi standard: 802.11ax (WiFi 6)
Operating frequency*
US/CA
Worldwide:
U-NII-1 5150 – 5250 MHz
U-NII-2A 5250 – 5350 MHz
U-NII-2C 5470 – 5725 MHz
U-NII-3 5725 – 5850 MHz
5150 – 5875 MHz
*Depends on regulatory region.
Channel bandwidth: 20, 40, 80 MHz
Modulation: BPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6)
Antenna gain: 13.5 dBi
Polarization: Dual-linear
Beamwidth: Azimuth: 6 dB 90°
Elevation: 6 dB 25°
Cross-pol isolation: 10 dB
Electric downtilt: 0°
