Technical Specification
LAN Activity Indicator: No
Gigabit LAN Port: No
Output Voltage: 15VDC @ 0.8A
Rated Voltage: 100-240VAC @ 50/60Hz
Input Current: 0.3A @ 120VAC, 0.2A @ 240VAC
Inrush Current: <30A Peak @ 120VAC, <60A Peak @ 230VAC
Switching Frequency: 50 kHz
2-Pair Powering: Pins 4, 5 (+) and Pins 7, 8 (-)
Data IN / POE: RJ45 Shielded Socket
Surge Protection: Difference and Common Mode
Clamping Protection: 11V Data, 60V Power
Max. Surge Discharge: 1500A (8/20 μs) Power
