Description
Appearance
Dimensions: 80 mm x 22 mm x 3.58 mm
Weight: 8g
Interface
Bus Interface: NVMe PCIe Gen3 x4
Storage
Flash Type: 3D NAND flash
Capacity: 256GB
Operating Environment
Operating Temperature: 0°C (32°F) ~ 70°C (158°F)
Operating Voltage: 3.3V±5%
Performance
Sequential Read/Write (CrystalDiskMark): 256 GB, 3,300/1,100 MB/s
4K Random Read/Write (IOmeter): 256 GB, 210,000/290,000 IOPS
Terabytes Written (TBW): 256 GB, 550 TBW
Mean Time Between Failures (MTBF): 2,000,000 hour(s)
Drive Writes Per Day (DWPD): 2.4 (5 yrs)
Note: Speed may vary due to host hardware, software, usage, and storage capacity.
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.
System Requirement
Operating System: Microsoft Windows 7 (additional driver required)
Microsoft Windows 8 (additional driver required)
Microsoft Windows 10
Linux Kernel 2.6.31 or later
