- 2.5G PoE+ Ports for WiFi 6: 8× 2.5 Gbps ports smash the gigabit barrier and unlock the full potential of WiFi 6 APs.
- 10G Lightning-Fast Uplink: 2× 10 Gbps SFP+ slots enable high-bandwidth connectivity and non-blocking switching capacity.
- 240 W PoE Budget: 8× 802.3at/af-compliant PoE+ ports with a total power supply of 240 W.
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Static Routing: Helps route internal traffic for more efficient use of network resources.
- Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
- Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
HARDWARE FEATURES
Interface:
– 8× 100/1000/2500 Mbps RJ45 Ports
– 2× 10G SFP+ Slots
– 1× RJ45 Console Port
– 1× Micro-USB Console Port
Fan Quantity: 2
Power Supply: 100-240 V AC~50/60 Hz
PoE Ports (RJ45):
– Standard: 802.3at/af compliant
– PoE+ Ports: 8 Ports
– PoE Power Budget: 240 W*
Dimensions ( W x D x H ): 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
Mounting: Rack Mountable
Max Power Consumption:
– V1: 291.49 W (110V/60Hz) (with 240 W PD connected); 17.24 W (110V/60Hz) (no PD connected)
– V2: 292.0W (110V/60Hz) (with 240 W PD connected)
Max Heat Dissipation:
– V1: 994.56 BTU/h (110 V/60 Hz) (with 240 W PD connected); 58.82 BTU/h (110 V/60 Hz) (no PD connected)
– V2: 996.35 BTU/hr (110 V/60 Hz) (with 240 W PD connected)
PERFORMANCE
Switching Capacity: 80 Gbps
Packet Forwarding Rate: 59.52 Mpps
MAC Address Table: 16 K
Packet Buffer Memory: 12 Mbit
Jumbo Frame: 9 KB
