- JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+
- 61 W PoE Budget: 8× 802.3af/at-compliant PoE+ ports with a total power supply of 61 W. Full Gigabit Ports: 8× gigabit PoE+ ports and 2× gigabit SFP Slots provide high-speed connections.
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, Radius Authentication, and more.
- Optimized Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
- Versatile Management: WEB/CLI managed modes, SNMP, and RMON bring abundant management features.
HARDWARE FEATURES
– Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab,
– IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s,
– IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Interface:
– 8× 10/100/1000Mbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX)
– 2× 1000Mbps SFP Slots
Network Media :
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
– 1000BASE-X: MMF, SMF
Fan Quantity: Fanless
Power Supply:
– 100~240VAC, 50/60Hz
– External Power Adapter(Output: 53.5VDC/1.31A)
Power Consumption:
– 10.3 W (220 V/50 Hz) (no PD connected)
– 76.5 W (220 V/50 Hz) (with 61 W PD connected)
PoE Ports (RJ45):
– Standard: 802.3af/at compliant
– PoE Ports: 8 Ports
– Power Supply: 61 W*
Dimensions ( W x D x H ): 8.2 x 4.9 x 1.0 in (209 x 126 x 26mm)
Mounting: Desktop / Wall-Mounting
Max Power Consumption:
– V3.2: 76.5 W (220 V/50 Hz) (with 61 W PD connected); 10.3 W (220 V/50 Hz) (no PD connected)
– V4: 74.4 W (220 V/50 Hz) (with 61 W PD connected)
– V5: 77.8 W (110 V/60 Hz) (with 61 W PD connected)
Max Heat Dissipation:
– V3.2: 261.02 BTU/hr (220 V/50 Hz) (with 61 W PD connected); 35.14 BTU/hr (220 V/50 Hz) (no PD connected)
– V4: 253.89 BTU/hr (220 V/50 Hz) (with 61 W PD connected)
– V5: 265.3 BTU/hr (110 V/60 Hz) (with 61 W PD connected)
