title: TP-Link TL-SG116 16-Port Gigabit Desktop Switch
date: 2024-09-02T20:11:00Z
modified: 2026-05-13T03:01:32Z
permalink: "https://tech.co.za/product/tp-link-tl-sg116-16-port-gigabit-desktop-switch/"
type: product
status: publish
excerpt: "16x 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX\\nGreen Ethernet technology saves power consumption\\nIEEE 802.3x flow control provides reliable data transfer\\nSteel housing, desktop or wall-mounting design\\nSupport 802.1p/DSCP QoS and IGMP Snooping function\\nPlug and play, with no configuration needed"
wpid: 501283
product_brand:
  - TP-Link
product_type:
  - simple
product_visibility:
  - featured
product_cat:
  - Networking
  - Switches
featured_image: "https://tech.co.za/wp-content/uploads/2024/09/switch-1-5.jpg"
---

**Specifications:**
Hardware Features
Standards and Protocols: IEEE 802.3i /802.3u /802.3ab /802.3x /802.1p
Interface: 16 10/100/1000Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX
Fan Quantity: Fanless
Physical Security Lock: Yes
External Power Supply: External Power Adapter (Output: 12VDC / 1.0A)
Dimensions ( W x D x H ): 286 x 111.7 x 25.4mm
Max Power Consumption: 10W(220V/50Hz)
Max Heat Dissipation: 34.12BTU/h


**Performance**
Packet Forwarding Rate: 23.8Mpps
MAC Address Table: 8K
Packet Buffer Memory: 4.1Mb
Jumbo Frame: 10KB
