- 48 10/100/1000Mbps RJ45 ports
- Innovative energy-efficient technology saves power consumption
- Supports MAC address self-learning and auto MDI/MDIX
- Standard 19-inch rack-mountable steel case

**HARDWARE FEATURES**
Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x

Interface: 48 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)

Physical Security Lock: No

Power Supply: 100-240VAC, 50/60Hz

Dimensions ( W x D x H ): 17.32_8.7_1.73 in.(440_220_44 mm)

Mounting: Rack Mountable

Max Power Consumption: 32.29W(220V/50Hz)

Max Heat Dissipation: 10.17BTU/h

**PERFORMANCE**
Switching Capacity: 96Gbps

Packet Forwarding Rate: 71.4Mpps

MAC Address Table: 16K

Buffer Memory: 12Mb

Jumbo Frame: 12KB

Transfer Method: Store-and-Forward
