- 24 10/100/1000Mbps RJ45 ports
- Innovative energy-efficient technology saves power consumption
- Supports MAC address self-learning and auto MDI/MDIX
- Standard 19-inch rack-mountable steel case
HARDWARE FEATURES
Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x
Interface: 24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity: Fanless
Physical Security Lock: No
Power Supply: 100-240VAC, 50/60Hz
Dimensions ( W x D x H ): 17.37.11.7 in. (44018044 mm)
Mounting: Rack Mountable
Max Power Consumption: 13.08W(220V/50Hz)
Max Heat Dissipation: 44.63BTU/h
PERFORMANCE
Switching Capacity: 48Gbps
Packet Forwarding Rate: 35.7Mpps
MAC Address Table: 8K
Advanced Functions:
Isolation Mode: Ports 1-22
Loop Prevention: Ports 1-24
Jumbo Frame: 10KB
QoS:
802.1p/DSCP QoS*
*Only for V11 and later version
Green Technology: Yes
Transfer Method: Store-and-Forward
