Management features
Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support: No
Port mirroring: Yes
Full duplex: Yes
Rate limiting: Yes
Auto MDI/MDI-X: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Flow control support: Yes
VLAN support: Yes
Number of VLANs: 32
Data transmission
Switching capacity: 32 Gbit/s
Throughput; 23.8 Mpps
MAC address table: 8000 entries
Store-and-forward: Yes
Number of queues: 4
Jumbo frames support: Yes
Jumbo frames: 9000
Packet buffer memory: 0.5 MB
Design
Rack mounting: Yes
LED indicators: Yes
Power
Power supply included: Yes
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
Power consumption (max): 11.73 W
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Weight & dimensions
Width: 294 mm
Depth: 180 mm
Height: 44 mm
