- 24 10/100M RJ45 ports.
- Innovative energy-efficient technology saves power up to 75%
- Supports MAC address self-learning and auto MDI/MDIX.
- Standard 13-inch steel case.

**HARDWARE FEATURES**
Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

Interface: 24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– 100BASE-TX: UTP category 5, 5e or above cable (maximum 100m)

Fan Quantity: Fanless

Physical Security Lock: Yes

Power Supply: 100-240VAC, 50/60Hz

Dimensions ( W x D x H ): 11.6\*7.1\*1.7 in. (294\*180\*44 mm)

Mounting: Rack Mountable

Max Power Consumption: 3.19W(220V/50Hz)

Max Heat Dissipation: 10.88BTU/h

**PERFORMANCE**
Switching Capacity: 4.8Gbps

Packet Forwarding Rate: 3.57Mpps

MAC Address Table: 8K

Buffer Memory: 2Mb

Green Technology: Innovative energy-efficient technology saves power up to 75%

Transfer Method: Store-and-Forward
