- AC1750 Dual Band Wi-Fi – Simultaneous 450Mbps on 2.4GHz + 1300Mbps on 5GHz
- Three Antennas – Three adjustable external antennas provide optimal Wi-Fi coverage and reliable connections
- Gigabit Ethernet port – Act as a wireless adapter to connect a wired device to your network at Gigabit speed
- Intelligent Signal Light – Help to find the best location for optimal Wi-Fi coverage by showing the signal strength
- AP Mode – Create a new Wi-Fi access point to enhance your wired network with Wi-Fi capability
- TP-Link Tether App – Easily access and manage your network using any iOS or Android mobile device
- Ultimate Compatibility – Extend the range of any Wi-Fi router or wireless access point
HARDWARE FEATURES
Standards and Protocols: IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Plug Type: EU, UK, US, AU, KR, JP
Interface: 1 x 10/100/1000M Ethernet Port (RJ45)
Ports: 1 Gigabit Ethernet Port
Button: WPS Button, Reset Button, LED Button, Power Button
Input Power: 100-240V~50/60Hz
Power Consumption: 10W（max power consumption）
Dimensions ( W x D x H ): 6.4 x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm)
Antenna: 3 x external
WIRELESS FEATURES
Wireless Standards: IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency: 2.4GHz & 5GHz(11ac)
Signal Rate: 5GHz:Up to 1300Mbps, 2.4GHz:Up to 450Mpbs
Working Modes: Range Extender / Access Point
Reception Sensitivity:
– 5GHz
11a 6Mbps:-93dBm@10% PER
11a 54Mbps: -76dBm@10% PER
11ac HT20 mcs8: -68dBm@10% PER
11ac HT40 mcs9: -64dBm@10% PER
11ac HT80 mcs9: -61dBm@10% PER
– 2.4GHz
11g 54M: -77dBm@10% PER
11n HT20 mcs7: -73dBm@10% PER
11n HT40 mcs7: -70dBm@10% PER
Wireless Modes: Range Extender / Access Point
Wireless Functions:
– Wireless Statistic
– Concurrent Mode Boost Both 2.4G/5G WiFi Band
– Access Control
– LED Control
– Domain Login Function
– Wi-Fi Coverage
Wireless Security: 64/128-bit WEP, WPA-PSK / WPA2-PSK
Transmission Power: <20dBm(2.4GHz), <23dBm(5GHz)
Mesh Technology: EasyMesh-Compatible
