- HomePlug AV standard compliant, high-speed data transfer rates of up to 600Mbps1
- Miniature design, smaller than most powerline adapters at the market, blends discreetly in front of any power outlet
- No new wires, Easy Plug and Play operation, No configuration required
- Patented Power-Saving Mode automatically reduces power consumption by up to 85%2
HARDWARE FEATURES
Standards and Protocols: HomePlug AV, IEEE802.3, IEEE802.3u
Plug Type: EU, UK, US
Interface: 1*10/100Mbps Ethernet Port
Button: Pair Button
Power Consumption:
– Maximum: 4.60W (220V/50Hz)
– Typical: 4.26W (220V/50Hz)
– Standby: 0.88W (220V/50Hz)
LED Indicator: PWR, PLC, ETH
Dimensions ( W x D x H ): 2.6 x 2.0 x 1.1 in.(65×52×28.5mm)
Range: Up to 300 meters/1000 feet over existing electrical wiring
SOFTWARE FEATURES
Modulation Technology: OFDM
Encryption: 128-bit AES Encryption
OTHERS
Certification: CE, FCC, RoHS
Package Contents:
– Powerline Ethernet Adapter
– Ethernet cable (RJ45)
– Quick Installation Guide
System Requirements: Windows 8/7/Vista/XP/2000, Mac, Linux
Environment:
– Operating Temperature: 0~40 (32~104)
– Storage Temperature: -40~70 (-40~158)
– Operating Humidity: 10%~90% non-condensing
– Storage Humidity: 5%~90% non-condensing
